Introduction

A flanged cryogenic gate valve is an isolation valve designed for pipelines carrying cryogenic media such as liquefied natural gas, liquid oxygen, and liquid nitrogen.

Parameter

Model	PDB100-C or OEM
Size Range	2"～30"
Pressure Range	150LB～2500LB
End Connection	Flanged end/Butt welding end
Valve Direction	Uni-directional
Temperature Range	Down to-196℃
Service	LNG/LN₂/LO₂ terminals, Air separation plants,LNG/LN₂/LO₂ transportation, and more
Operation	Handwheel, Gearbox, Pneumatic actuator, and more
Material
Body	A351 CF8M, etc.
Trim	HF/HF
Basic Design	API 600, ASME B16.34, MESC SPE 77/200
Face to Face	ASME B16.10
Flange End	ASME B16.5
Butt Welding End	ASME B16.25
Test and Inspection	API 598, MESC SPE 77/200
Fire-safe Test	API 6FA or API 607
Manufacturing to NACE latest version on request 6364, MSS SP-134, are also available CSA Z245.15 latest version compliance is available.

Features

Bidirectional Hard Seal

Both the valve body sealing surface and the gate sealing surface utilize hard seal welding, resulting in superior sealing performance and durability compared to single-sided welding.

Flexible Operation

Optional handwheel, gearbox, and pneumatic actuator options are available to suit different operational efficiencies and automation requirements.

Stainless Steel Valve Body

The flanged cryogenic gate valve is made of A351 CF8M material, possessing excellent corrosion resistance and low-temperature toughness.

FAQ

Q: How many different types of products does your company manufacture?

A: Now we have more than 30 products. We have a strong advantage of OEM. Just give us the actual products or your idea that you want, and we will manufacture them for you.

Q: When can I get the price?

A: Usually, we quote within 8 hours after we get your inquiry.

Q: What's your MOQ?

A: For 2pc/3pc screwed body valves & castings &sealing materials, we have the products or parts in stock.

Q: How long is your delivery time?

A: The general delivery time is 30-45 days after receiving your order confirmation. Another, if we have the goods in stock, it will only take 1-2 days. Anyway, it will depend on which kind of valves or actuators you need.

Q: Do you provide a sample? Is it free?

A: If the sample is of low value, we will provide the free sample with freight collect. But for some high-value samples, we need to collect the sample charge.
